PRODUCTS
Impulse Type
EH-420/EH-600 (Single Heater)
A standard type foot-operated impulse sealer, requiring no pre-heating time. Its simple structure ensures easy maintenance and reliable operation. Sealing is activated by a foot switch and controlled by a built-in timer. Equipped as standard with casters and a slide table.
| Machine Dimensions | (EH-420) 510x530x1050mm |
| Machine Dimensions | (EH-600) 690x590x1070mm |
| Weight | (EH-420) 30kg (EH-600) 40kg |
| Power Required | (EH-420) 100V 300W (EH-600) 400W |
| Max. Bag Width | (EH-420) 420mm (EH-600) 600ｍｍ |
| Sealing Width | (EH-420/EH600) 3ｍｍ |
EH-420-AC/EH-600-AC (Air Cylinder Type)
These modesl use an air cylinder system, ensuring consistent sealing time, cooling time, and pressure. Models featuring air cylinders are marked with “AC”. Equipped as standard with casters and a vertical slide table. Note: This model requires an air consumption of 50 NL/min.
| Machine Dimensions | （ EH-420AC）510×530×1050mm |
| Machine Dimensions | （EH-600AC）690×490×1030mm |
| Weight | （EH-420AC）30kg（EH-600AC）40kg |
| Power Required | （EH-420AC）100V 400W（EH-600AC）650W |
| Max. Bag Width | （EH-420AC）420mm（EH-600AC）590ｍｍ |
EH-600D (Double Heater for Thick Bags)
EH-600D is equipped with upper and lower heaters, making it suitable for sealing thick bags. 600 insists maximum bag width and D for double heater type. Available for 100V and 200V.
| Machine Dimensions | 750x490x1070mm |
| Weight | 40kg |
| Power Required | 100V 1200W |
| Max. Bag Width | 600ｍｍ |
EHB-800/EHB-1000 (Wide Sealing Width)
This is a custom-made impulse sealer designed with an extra-wide seal width. Available in two sizes: 800 mm and 1000 mm. Equipped as standard with casters and a slide table.
| Machine Dimensions | （EHB-800）956x555x1060mm |
| Machine Dimensions | （EHB-1000）1220x550x1065mm |
| Weight | （EH-800）60kg（EH-1000）70kg |
| Power Required | （EH-800）100V 1000W（EHB-1000） 120W |
| Max. Bag Width | （EH-800）800mm（EH-1000）1000mm |
